HD 1080P 20X Zoom HDMI USB PTZ Video Conference Camera for Video Conference
55°horizontal angle
SONY 2.38 mega pixel
USB/HDMI/SDI video output
20X zoom HD1080P(1920*1080)
- Бърза доставка
- Гарантиране на качеството
- Денонощно обслужване на клиенти
представяне на продукта
HD 1080P 20X Zoom HDMI USB PTZ Video Conference Camera for Video Conference
PRESET+Number: To set preset position of this number.
RESET+Number: To clear preset position of this number.
Preset: 10 via IR remote setting (255 via RS232)
Wide field of view with no video distortion
1/3 inch high quality, 2.38MP (16:9) CMOS sensor
Superior quality with Full Glass Lens Material
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
2D and 3D NR for best video quality in different lighting conditions
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
Compatible with most leading video conferencing software and platform
| Model | UHD10N | UHD12N | UHD20N | UHD30N |
| Sensor | 1/2.8''SONY CMOS | |||
| Effective pixel | 2.38 mega pixel | 2.38 mega pixel | ||
| Video signals | 1080p-30/25, 1080i-60/50,720p-30/25 | |||
| Zoom | 10x optical zoom | 12x optical zoom | 20x optical zoom | 30x optical zoom |
| Lens | f=4.34mm～35.17mm | f=3.85mm～46.2mm | f=5.5-110mm | f=4.7～141mm |
| Aperture | F1.85～2.63 | F2.4～F4.0 | F1.6～3.5 | F1.5～4.0 |
| Horizontal angle | 68.8°(W)-8.8°(T) | 73.0°(W)-6.97°(T) | 58.6°(W)-3.6°(T) | 60.5°(W)-2.3°(T) |
| Vertial angle | 39.5°(W)-5.1°(T) | 43.1°(W)-3.92°(T) | 54.7°(W)-3.3°(T) | 35.1°(W)-1.3°(T) |
| Diagonal angle | 77.2°(W)-10.1°(T) | 81.1°(W)-7.99°(T) | 60.2°(W)-3.7°(T) | 69.5°(W)-2.7°(T) |
| Video output | USB,HDMI,SDI,RJ45 | |||
| Video encoding format | MJPEG/YUY2/H.264 | |||
| Video resolution | 1080P (1920 *1080) etc | |||
| Siginal standard | NTSC/PAL | |||
| Preset position | User can set up to 64 presets (IR remote 10 presets) | |||
| Control terminal | RS-232,RS485 | |||
| Shutter | 1/30s～1/10000s, auto | |||
| Baud rate | 38400/9600bps | |||
| Control protocol | VISCA, PELCO-D, PELCO-P(RS-232, RS485) | |||
| USB protocol | UVC1.1 | |||
| Minimal Illumination | 0.1Lux | |||
| SNR | ≥50dB | |||
| Horizontal rotation | 350°（±175°）0.1°/s～100°/s | |||
| Vertical rotation | 180°（±90°）0.1°/s～80°s | |||
| Power supply | DC 12V/2A | |||
| Power consumption | 12W | |||
| Work temperature | 0°~+50° | |||
| Work humidity | 0~95% RH | |||
| Product size | 212*160*172mm/260*217*197mm (before / after packing) | |||
| Product weight | 1.25kg/2.05kg(net / gross weight) | |||
What's in the box?
1 x Camera
1 x DC 12V power adaptor
1 x IR remote control
1 x Manual
1 x USB cable
1 x Brackets & screws
